Automatic Pipe Flange Welding Machine (GTAWTIG)
Model: PFAWC-16Ba/24Ba/32Ba/48Ba/64Ba
Technical Parameters- Pipe Diameter Applicable: DN400/DN600/DN800/DN1200/DN1600
- Pipe Wall Thickness Applicable: 3-20MM
- Applicable Materials: Carbon steel, alloy steel, stainless steel and cryogenic steel, etc.
- Welding Line Applicable: Welding line of flange pipe
- Machine Head System: One welding head with two welding guns at one end/two welding heads with four welding guns both at two ends
- Driving System: Driven the motor of active idler wheel frame
- Clamping System: Clamped by chain or contact roller
- Bracket System: Two sets of motorized idler wheel to be set and it is adjustable according to the pipe length along the track
- Speed Regulation Mode: VF stepless speed control system
- Adjustment Mode: Electric cross regulator
- Swaying System: A product of our patented technology, driven by step motor and oscillating adjusting with digital display
- Control System: A product of our patented technology
- Welding Procedure: GTAW/TIG
- Welding Power: OEM products in China (or as per customers' demands)
Applications
Slip-on flange for the welding of the internal and external incidence angle.
- The automatic pipe flange welding machine offers excellent welding capacity (150-250 inch/day, which is four times higher than manual welding).
- The machine is easy to operate.
- The automatic pipe flange welding machine offers excellent surface forming.
- It offers a welding compliance rate (without re-working for the skilled operator).
- The automatic pipe flange welding offers good driving reliability.
- Classic product; widely used in industries like shipbuilding, mining, irrigation; suitable for welding pipe segments such as “flange + pipe + flange”; welding efficiency increased by more than 200%; one fixed-type wheel rotator; one movable wheel-supporting trolley; two movable welding trolleys; standard configuration: four Lincoln CV500 inverter welding power supplies; welding synchronously at inner and outer fillet with four MIG welding torches; operated with aluminum alloy control box.
As a China-based automatic pipe flange welding machine manufacturer and supplier, we provide a comprehensive range of products that includes pipe automatic welding machine, high speed pipe end beveling machine, slip-on flange and pipe fast fitting-up machine, and more.
