Automatic Pipe Welding Machine (FCAW/GMAW)

This product has been discontinued and removed from our shelves.

Automatic Pipe Welding Machine (FCAW/GMAW)
  • Automatic Pipe Welding Machine (FCAW/GMAW)
  • Automatic Pipe Welding Machine (FCAW/GMAW)
  • Automatic Pipe Welding Machine (FCAW/GMAW)
  • Automatic Pipe Welding Machine (FCAW/GMAW)
  • Automatic Pipe Welding Machine (FCAW/GMAW)
  • Automatic Pipe Welding Machine (FCAW/GMAW)
  • Automatic Pipe Welding Machine (FCAW/GMAW)

    • Model: PPAWM-16Aa/24Aa/32Aa

    Technical Parameters
    • Pipe Diameter Applicable: DN50-400 (φ60-426)/DN50~600(φ60~610)/DN200-800(φ219-813)
    • Pipe Wall Thickness Applicable: 3~30MM
    • Applicable Materials: Carbon steel, alloy steel, stainless steel and cryogenic steel
    • Welding Line Applicable: Various butt welding lines of spool pieces such as pipe-pipe, pipe-elbow, pipe-flange, flange-flange and flange-elbow, etc. (a fake pipe transition connection shall be applied if necessary)
    • Driving System: Driven by two line rubber roller and reducer
    • Clamping System: Clamping arm moves up and down electrically and clamps by screw with telescope boom
    • Bracket System: Separate type of trolley matching for welding equipment which may be adjusted along the track according to the length of the pipe
    • Counterweight System: No counterweight
    • Speed Regulation Mode: VF stepless speed control system
    • Adjustment Mode: Electric cross regulator
    • Oscillating System: A product of our patented technology
    • Control System: A product of our patented technology, PLC control
    • Welding Procedure: FCAW/GMAW (can do root pass, filling, and final welding)
    • Welding Power: OEM products in China or as per customers' demands

    Applications
    The automatic pipe welding machine offers extremely broad use for the pipe and cover welding of various structures in various industries.

    Features
    • The automatic pipe welding machine offers excellent welding capacity (250-350 inch/day, which is four times higher than the manual welding).
    • The machine is easy to operate
    • The automatic pipe welding machine offers excellent surface finishing.
    • It offers welding qualification rate: (without re-working for the skilled operator).
    • The automatic pipe welding offers good driving reliability. However, driven by frictional force, it is required to set essential balance weight to offset large bending moment caused by elbows for large diameter pipe, or providing a chain tensioner to improve the reliability of the driving.
